3D Harness Design Optimization

Merges designs from heterogeneous sources and provides comprehensive design exploration.

Unnamed
Zuken
Screen Shot 2019 05 15 At 10 19 33 Am
Zuken

Zuken introduces E3.WiringSystemLab, a new software solution that enables the optimization of complex wire harness designs based on inputs from heterogeneous sources.

The product can import connectivity information from a broad range of sources and consolidates them with 3D topology data. The resulting 3D topology can be evaluated and optimized in a consistent 3D environment that has been designed to support the needs of casual users without requiring specialized training.

Connectivity data can be imported from:

  • E3.cable

  • KBL

  • VEC

  • PLMXML

  • Excel

For more information, visit https://us.zuken.com/e3series-home/e3-wiring-system-lab/
