10 GHz Mixed Signal Oscilloscope

Offers increased bandwidth, lower noise and more channels.

Tek Mso68 B 11 (1)
Tektronix

Tektronix announces the availability of the new 6 Series B Mixed Signal Oscilloscope (MSO), which extends the performance threshold of the Tektronix Mainstream Oscilloscopes Portfolio to 10 GHz and 50 GS/sec.

Developed to meet the demand for high-speed data movement and processing in embedded designs, the enhanced 6 Series B MSO offers leading signal fidelity with12-bit ADCs and extremely low noise, 10 GHz bandwidth and up to 8 FlexChannel inputs, enabling users to confidently analyze and debug today’s embedded systems while enjoying exceptional ease of use.

Alongside the 6 Series B MSO, Tektronix is also introducing the new TDP7710 TriMode Probe, which extends the line of TriMode probes to match the advancements of the new oscilloscope.

The new 6 Series B MSO goes beyond the expected, allowing top manufacturers to bring cutting-edge and higher performance products to industrial, medical, consumer and computer markets. This instrument is poised for higher-speed embedded designs, demanding mixed-signal design troubleshooting and accelerating serial bus speeds. The 6 Series B MSO is also highly-effective for diverse applications in semiconductors, power integrity, automotive, defense, aerospace, research and beyond.

The 6 Series B MSO offers a superior combination of bandwidth, sample rate, vertical resolution, low noise and high ENOB, providing exceptional measurements and confidence. With up to 10 GHz of fully-upgradable bandwidth and up to 50 GS/s sample rate, users have better visibility of signals in high-performance designs.

This instrument delivers industry-leading signal fidelity, contributing less than 51.1 μV of noise at 1 mV/div and 1 GHz, and less than 1.39mV of noise at 50 mV/div and 10 GHz. The 6 Series B MSO is the industry’s first oscilloscope with bandwidth more than 2 GHz to offer 4, 6 or 8 channels. Each FlexChannel input can be converted into 8 digital channels using a TLP058 Logic Probe for added visibility.

For more information, visit https://tek.com/6-series-mso-mixed-signal-oscilloscope.
