Low Viscosity Epoxy Coating

Withstands prolonged exposure to a wide range of chemicals.

Screen Shot 2020 09 24 At 11 42 36 Am
Master Bond
Mb Logo

Master Bond EP21ARLV is a two-part epoxy that may be used as an adhesive, sealant, coating or encapsulant. The product is capable of withstanding prolonged exposure to a wide range of chemicals, such as 70% sulfuric acid, 10% hydrochloric acid, 10% nitric acid and butyl acetate to name a few.

Both parts A and B have a low viscosity of 3,000-6,000 cps and 4,000-6,000 cps, respectively. The mix ratio of EP21ARLV is 100 to 50 by weight, and it cures at room temperature. However, the addition of heat not only speeds up the curing process but it is also vital for optimizing acid resistance.

It is a reliable electrical insulator with a volume resistivity greater than 1014 ohm-cm at 75°F, and dielectric strength of 440 volts/mil at 75°F, for a 1/8 inch test sample.

Other noteworthy properties include:

  • Tensile strength of 8,000-9,000 psi
  • Shore D hardness of 80-90
  • Tensile modulus of 350,000-400,000 psi
  • Temperature range of -60°F to +250°F.

This compound bonds well to a variety of substrates including metals, ceramics, composites and many plastics and rubbers. Read more at https://www.masterbond.com/properties/chemical-resistance.
