IoT Gateway Mini-ITX Platform

High-performance factory-process visualization support and communications from factory line to cloud.

Mb 50040 Hi Res
WIN Enterprises
Screen Shot 2019 12 17 At 11 43 15 Am
WIN Enterprises

WIN Enterprises announces the MB-50050, a mini-ITX SBC to serve as the basis for a flexible, general-purpose IoT gateway.

The board features an 9th/8th Gen Intel Core processor for high performance, factory-process visualization support and communications from factory line to cloud.

Features include:

  • 2 DDR4 2666MHz SODIMM up to 32GB
  • Dual independent displays: DP++ + DP++, DP++ + HDMI, DP++ + LVDS/eDP, HDMI+ LVDS/eDP
  • DP++ resolution supports up to 4096x2304 @ 60Hz
  • Storage: 2 SATA 3.0
  • Multiple Expansion Capability: 1 PCIe x4 Gen 3, 1 mSATA, 1 M.2 2280 M Key, 1 M.2 2230 E Key
  • Rich I/O: 2 Intel GbE, 4 COM, 4 USB 3.1 Gen 1, 4 USB 2.0

Because IoT gateways need to provide rich serial communications capability to handle factory line input and communications, the MB-50050 was designed with robust serial communications that includes 4 COM, 4 USB 3.1 Gen 1, and 4 USB 2.0, plus up to 4 expansion interfaces. The MB-50050 supports dual independent displays with one of these being high resolution (i.e., 4096x2304) to enable sophisticated process visualization of the factory-line processes.

Meaningful communications with the cloud requires robust memory, storage and connectivity. The MB-50050 provides this with 2x DDR4 to process the raw factory-line data into information, 2x SATA 3.0 for storage, and 2x Intel GbE LANs for communications with the cloud and other IoT elements on the network.

For more, visit https://win-ent.com.
