Single Pair Ethernet Push-Pull Connector

Operates over a single twisted-pair copper cable supporting an effective data rate of 1 gigabit per second.

Screen Shot 2020 02 05 At 11 08 52 Am
Lemo
Screen Shot 2019 01 07 At 10 19 09 Am
Lemo

Based on transmission standards IEEE 802.3, single-pair Ethernet — also called SPE or 1000Base-T1 — is integrated into new generations of automobiles.

1000Base-T1 is designed to operate over a single twisted-pair copper cable supporting an effective data rate of 1 gigabit per second in each direction simultaneously.

LEMO provides two types of insulators 0B.511(2 contacts) and 1B.512 (4 contacts + screen) compatible with Unshielded Twisted Pair (UTP) and Shielded Twisted Pairs (STP).

The new product is available in the B series and also in a watertight version: the T series connector. The connectors are initially designed for automotive and industrial data transfer. The role of SPE is also to gain space and weight (with a more simple cable) and can be used in other markets such as machine, robotics and rail technology.

Find out more at https://www.lemo.com/catalog/ROW/UK_English/connector_SPE_single_pair_ethernet_1000BaseT1.pdf.
