0.15-Micrometer Gate Technology

GaN process for high-power mmWave applications and 5G infrastructure.

Win Np15 Series Pr Image
WIN Semiconductor
Screen Shot 2019 10 16 At 11 51 13 Am
WIN Semiconductors

WIN Semiconductors Corp. has expanded its gallium nitride (GaN) portfolio with the commercial release of a 0.15-micrometer gate technology, NP15-00, that supports emerging mmWave PA applications including radar, satellite communications and 5G massive MIMO infrastructure.

The NP15-00 technology supports full MMICs enabling WIN customers to design compact, linear or saturated high power amplifiers through 35GHz.

The NP15-00 gallium nitride technology employs a source-coupled field plate for improved breakdown voltage, and operates at a drain bias of 20 volts. This technology is fabricated on 100mm silicon carbide substrates with through-wafer vias for low inductance grounding. In the 29GHz band, NP15-00 offers saturated output power of 3 watts/mm with 13 dB linear gain and greater than 50% efficiency without harmonic tuning.

For more information, visit WIN Semiconductors Corp. at http://www.winfoundry.com/en_US/Index.aspx.
