STMicroelectronics Integrated Matching Filters Available for Long-range Wireless Microcontrollers

Chip-scale ICs built with proprietary ST technology.

STMicroelectronics Wireless MCUs.
STMicroelectronics Wireless MCUs.
STMicroelectronics

Recently, STMicroelectronics (GENEVA, SWITZERLAND) introduced a new set of antenna-matching companion chips—MLPF-WL-01D3, MLPF-WL-02D3, and MLPF-WL-04D3—designed for STM32WL33 wireless microcontrollers in IoT, smart metering, and remote monitoring applications.

The MLPF-WL-0xD3 chips provide impedance matching and harmonic filtering to improve RF performance and simplify antenna integration with STM32WL33 wireless MCUs.

Features & Benefits:

  • Combines impedance matching and harmonic filtering on a single glass substrate.

  • Supports both high-band (826–958 MHz) and low-band (413–479 MHz) operation.

  • Compatible with high-power (16 dBm/20 dBm) and low-power (10 dBm) output modes.

  • Designed for 2-layer or 4-layer PCB implementations.

  • Includes integrated antenna protection for streamlined RF connectivity.

  • Offers reduced bill-of-materials and board space through integration.

  • Maintains performance across temperature changes using non-conductive glass substrate.

  • Ultra-compact chip-scale package: 1.47 mm Ă— 1.87 mm Ă— 630 µm.

  • Available in seven variants for application-specific optimization.

Suitable for STM32WL33-based designs in smart city, smart agriculture, and industrial applications including smart meters, asset tracking, safety systems, and proximity detection.

For more information, visit the STMicroelectronics webpage.
