Peltier Coolers for Smart Automotive Headlights

Operate in elevated temperatures providing spot cooling for sensitive electronics.

Laird Thermal Systems Auto Image
Laird Thermal Systems
Laird Thermal 5c1bd65d89255
Laird Thermal Systems

Digital light processing technology is now used in many smart automotive headlight systems to cast sharper and brighter light in front of a vehicle. These automotive headlight systems operate in temperature environments that can reach 110°C. However, the maximum operating temperature of a DLP is only 70°C. Going beyond the temperature limits of a DLP risks non-operation or failure. Implementing a HiTemp ET Series thermoelectric cooler module protects the sensitive DLP electronics and ensures optimum performance.

The HiTemp ET Series is a Peltier cooler that delivers active spot cooling. The HiTemp ET Series can lower the control temperature by as much as 40°C below ambient dependent on active heat load. The Peltier cooler offers reliable solid-state construction, long life operation, and a compact form factor that fits into tight space constraints commonly found in automotive headlights. In addition, Peltier coolers do not outgas, eliminating the coating build up on lens surfaces that can occur over time.

Compared to passive cooling solutions, the active HiTemp ET Series can be integrated similarly into a DLP automotive headlight system. A cold block and interface material are typically used on the cold side and comes in direct contact with the DLP. The cold block then comes in contact with the Peltier Cooler. When power is applied to the HiTemp ET Series, heat is absorbed by the Peltier Module and pumped to the hot side. A heat dissipation mechanism, which is typically a heat sink and fan, then rejects the heat into the surrounding environment.

For more information, visit https://www.lairdthermal.com/products/product-series/hitemp-et-series.
