Wire-to-Board Connector System

Provides electrical and mechanical reliability in a high-temperature design.

Micro Lock Plus200 Sng Ra 5055700801 5055780801 Mating
Molex
Screen Shot 2019 02 21 At 10 01 19 Am
Molex

Molex has released a new Micro-Lock Plus Wire-to-Board Connector System for users in the automotive, industrial and consumer applications, designed to provide reliable electrical and mechanical performance in a compact, high-temperature design.

Customers needing a compact wire-to-board connector with a high-current rating up to 3.0A will benefit from the new system.

The connector system comes in two sizes: 2.00mm pitch and 1.25mm pitch.

The 2.00mm pitch version:

  • Offers 2 to 16 circuits in a single row

  • Vertical and horizontal configurations

  • Connector with a positive lock

  • Outer lock to provide extra strength

  • SMT terminals to prevent whiskering

  • Metal tabs that reduce strain on solder joints

  • Dual contact points in an expanded terminal and lance area.

The 1.25mm pitch version:

  • Includes a variety of colors

  • Up to 42 circuits in single and dual rows

  • Inner lock for dual connections

  • Outer lock for single connections.

For more information, please visit www.molex.com/link/microlockplus.html.
