In-Circuit Debugger and Programmer

Streamlines debug/program for MCUs and DSCs.

Print Microchip Mplab Snap
Mouser Electronics

Mouser Electronics is now stocking the MPLAB Snap in-circuit debugger and programmer from Microchip Technology. The MPLAB Snap provides affordable, fast, and easy debugging and programming of most PIC, AVR and SAM flash microcontrollers and dsPIC digital signal controllers using the powerful graphical user interface of MPLAB X integrated development environment.

  • Features a powerful 32-bit 300 MHz SAM E70 Arm Cortex-M7 based microcontroller for quicker debug iterations.
  • Debugger system executes code like an actual device because it uses the target device’s built-in emulation circuitry, instead of a special debugger chip.
  • Board connects to a computer via high-speed USB 2.0 interface and can be connected to the target device through an 8-pin single in-line header.

To learn more about the Microchip MPLAB Snap, visit www.mouser.com/microchip-mplab-snap
