Autonomous Excavator Constructs Six-Meter-High Dry-Stone Wall

WATCH: The excavator can autonomously draw a 3D map and localize existing building blocks and stones.

Image imageformat lightbox 1753063285
ETH Zurich

ETH Zurich researchers deployed an autonomous excavator, called HEAP, to build a six meter-​high and sixty-​five-meter-long dry-​stone wall. The wall is embedded in a digitally planned and autonomously excavated landscape and park.

The team of researchers included Gramazio Kohler Research, the Robotics Systems Lab, Vision for Robotics Lab and the Chair of Landscape Architecture. They developed this innovative design application as part of the National Centre of Competence in Research for Digital Fabrication (NCCR dfab).

Using sensors, the excavator can autonomously draw a 3D map of the construction site and localize existing building blocks and stones for the wall’s construction. Specifically designed tools and machine vision approaches enable the excavator to scan and grab large stones in its immediate environment.

It can also register their approximate weight as well as their center of gravity. An algorithm determines the best position for each stone, and the excavator then conducts the task itself by placing the stones in the desired location. The autonomous machine can place 20 to 30 stones in a single consignment – about as many as one delivery could supply.
