Nabors Automates Existing Land Rig with Robotics Module

Nabors retrofitted an existing rig and has successfully drilled multiple horizontal wells for ExxonMobil.

Nabors Rzr Rig Floor
Nabors

Nabors Industries announced today the launch of its Canrig Red Zone Robotics (RZR) Rig Floor Module, a modular rig upgrade that automates routine drilling activities.

Nabors retrofitted an existing rig – X29 – with RZR (pronounced razor) and has successfully drilled multiple horizontal wells for ExxonMobil in the Permian Basin.

In 2021, Nabors and ExxonMobil proved fully automated land drilling is possible with Nabors' newbuild R801 robotic drilling rig. Now, the companies have advanced to the next phase of their collaboration to validate the use of modular rig retrofits as a viable path to scale drilling rig automation.

Rig Floor Automation Improves Safety and Consistency

Red zones have traditionally been particularly hazardous workspaces in the oil and gas industry. Over the next several years, Nabors believes that customers will increasingly demand and require automated pipe handling and further integration of robots into red zones to deliver safety and ESG commitments.

According to the International Association of Drilling Contractors, about 64% of 2021 lost time injuries in the Lower 48 involved the catwalk, pipe rack, rig floor or derrick. RZR automates activities in those areas, clearing crew members from red zones. And as Nabors automates their rigs, with the same number of workers, they expect to add incremental services to their rig platform thus bringing more value to the Company and to their customers.

RZR is electric powered, allowing precision control and digital workflows. It enables completely hands-free pipe handling and eliminates the need for a crew member to be positioned on the floor and in the derrick. The system autonomously performs repetitive tasks on the rig floor, including making drilling connections, and tripping in and out of hole. RZR enables offline stand building and handles casing in upper, intermediate and production sizes.

All Nabors RZR features are enabled through its proprietary rig operating system, SmartROS™, which can be installed on existing rigs and control third party rig manufacturer's equipment. RZR is modular and may be deployed on most standard rig configurations to optimize drilling operations and achieve consistently best-in-class performance.

RZR Rig Floor Upgrade is a Fraction of the Cost of a Newbuild

Nabors equipped X29 with RZR at a fraction of the cost of a newbuild rig. These capital light upgrades can be used today to elevate drilling performance on existing assets instead of building fully automated rigs progressively over time.

Applying Lessons from R801 Drilling Campaign to New RZR Initiative

The world's first fully automated land drilling rig, R801 is a purpose-built proving ground and launchpad for drilling automation. Nabors and ExxonMobil recently drilled nine wells with R801 with zero recordable incidents and well times approaching Nabors' best West Texas fleet averages.

As Nabors and ExxonMobil progress to the next stage in their technology collaboration, learnings from the R801 campaign have been applied to RZR's deployment, to rapidly scale up the use of modular rig upgrades as a path to full automation.
